Chapter 6 Compliance Test
167
6.2.3 HDMI Repeater Test
When a test ID number is clicked with the mouse, the selected test is started. While testing is in progress, the
EDIDs required for the tests are set automatically. The following shows the test list. For details on each test,
refer to the MOI.
Test list
TEST ID
Name
Description
HF3-21
Repeater Repeated Output Port HDR
Checks that the repeater device connected with VA-
1842 sends Dynamic Range and Mastering InfoFrame
correctly when repeating HDR content.
HF3-22
Repeater Repeated Output Port Source
Functionality HDR
Checks that the repeater device connected with VA-
1842 sends Dynamic Range and Mastering InfoFrame
correctly when sending HDR content.
HF3-23
Repeater Repeated Input Port HDR
Checks that the EDID of the repeater device connected
with the VA-1842 is set correctly.
HF3-24
Repeater Repeated Input Port Sink
Functionality HDR
Checks that the EDID of the repeater device connected
with the VA-1842 is set correctly.
* Includes items not approved as an MOI. For details, refer to the latest HDMI CTS.
