ASTRO VA-1842 - Chapter 11 Error List; ANALYZE ERROR (Red Display) List; Video Timing

359
11
Error List
11.1 ANALYZE ERROR (Red Display) List
11.1.1 Video Timing
Item
Description
Pixel Clock
When Video Code of AVI InfoFrame is (1-107), this frequency is not within ±0.5% of the
value specified in the format designated for Video Code.
H Frequency
When Video Code of AVI InfoFrame is (1-107), this frequency is not within ±0.5% of the
value specified in the format designated for Video Code.
V Frequency
When Video Code of AVI InfoFrame is (1-107), this frequency is not within ±0.5% of the
value specified in the format designated for Video Code.
H Total Pixels
When Video Code of AVI InfoFrame is (1-107), the number of pixels differs from the value
specified in the format designated for Video Code.
H Active Pixels
When Video Code of AVI InfoFrame is (1-107), the number of pixels differs from the value
specified in the format designated for Video Code.
H Sync Pixels
When Video Code of AVI InfoFrame is (1-107), the number of pixels differs from the value
specified in the format designated for Video Code.
H Back Porch Pixels
When Video Code of AVI InfoFrame is (1-107), the number of pixels differs from the value
specified in the format designated for Video Code.
H Front Porch Pixels
When Video Code of AVI InfoFrame is (1-107), the number of pixels differs from the value
specified in the format designated for Video Code.
H Sync Polarity
When Video Code of AVI InfoFrame is (1-107), the polarity differs from the value specified
in the format designated for Video Code.
V Total Lines
When Video Code of AVI InfoFrame is (1-107), the number of lines differs from the value
specified in the format designated for Video Code.
V Active TOTAL
When Video Code of AVI InfoFrame is (1-107), the number of lines differs from the value
specified in the format designated for Video Code.
V Sync Field1
When Video Code of AVI InfoFrame is (1-107), the number of lines differs from the value
specified in the format designated for Video Code.
V Back Porch Field1
When Video Code of AVI InfoFrame is (1-107), the number of lines differs from the value
specified in the format designated for Video Code.
V Front Porch Field1
When Video Code of AVI InfoFrame is (1-107), the number of lines differs from the value
specified in the format designated for Video Code.
V Sync Polarity
When Video Code of AVI InfoFrame is (1-107), the polarity differs from the value specified
in the format designated for Video Code.
Interlace
When Video Code of AVI InfoFrame is (1-107), this method differs from the value
specified in the format designated for Video Code.
