Chapter 12 VA-1842 Specifications
375
12.3
Option Specifications
12.3.1 Through Box
This option allows you to monitor the DDC, CEC, and Hot Plug Detect signals on the VA-1842 by connecting
the input and output of HDMI to the source and sink, respectively, and then connecting THROUGH OUT to the
VA-1842.
All HDMI signals are passed through without the VA-1842 being placed directly between the source and sink.
■ HDMI input and output
Item
Specifications
Input/output signals
TMDS
TMDS CLK
25 to 225MHz
HDCP
Pass through
E-EDID
Pass through
CEC
Pass through
* This function is optional. For details, consult with an ASTRODESIGN sales representative.
