2.2 Connection Example in Repeater Mode
Set the VA-1842 as a repeater to perform HDMI protocol analysis of an HDMI output device.
By connecting an HDMI compatible monitor to the HDMI output of the VA-1842, you can check that an output
device is operating normally as repeater support.
When you will use the VA-1842 as a repeater, select the icon before use.
Device with HDMI output terminal
DVD player, etc.
Device with HDMI input
terminal
LCD TV, etc.
To Next Page
