Chapter 6 Compliance Test
247
6.5.2 HDCP2.2 CTS 1A
When a test ID number is clicked with the mouse, the selected test is started. While testing is in progress, the
settings required for the tests are set automatically. The following shows the test list.
Test list
TEST ID
Name
Description
1A-01
Regular Procedure – With previously
connected Receiver (With stored km)
Performs a check of the HDCP protocol for when a
receiver is connected to the DUT.
1A-02
Regular Procedure – With newly connected
Receiver (Without stored km)
Performs a check of the HDCP protocol for when a
receiver without km stored is connected to the DUT.
1A-03
Regular Procedure – Receiver disconnect
after AKE_Init
Performs a check of the HDCP protocol for when the
receiver is disconnected and connected and
authentication is performed again after sending
AKE_Init.
1A-04
Regular Procedure – Receiver disconnect
after km
Performs a check of the HDCP protocol for when the
receiver is disconnected and connected and
authentication is performed again after sending Km.
1A-05
Regular Procedure – Receiver disconnect
after locality check
Performs a check of the HDCP protocol for when the
receiver is disconnected and connected and
authentication is performed again after the locality
check.
1A-06
Regular Procedure – Receiver disconnect
after ks
Performs a check of the HDCP protocol for when the
receiver is disconnected and connected and
authentication is performed again after sending
SKE_Send_Eks.
