Chapter 4 Source ANALYSIS
99
Experiment products not for commercial sale
Not define. Reserved
Not define. Reserved, espect 000 0000 and 000 0001 L
Source number
Do not take into account.
1 - 15 CH
Channel
number
Do not take into account.
A - O (0x1:A; 0x2:B; …… 0xF:O)
Sampling
frequency
44.1kHz
no indicate
48kHz
32kHz
88.2kHz ( - HDMI Original )
96kHz ( - HDMI Original )
176.4kHz ( - HDMI Original )
192kHz ( - HDMI Original )
768kHz ( - HDMI Original )
Clock accuracy
Level 2, ±1000ppm (default)
Level 1, ±50ppm - high accuracy
Level 3, variable pitch
Reserved
Max sample
length
20bit
24bit
Sample word
length
Maximum audio sample word length = 20 bit
Word length not indicated (default )
16bits
18bits
19bits
20bits
17bits
Reserved
Maximum audio sample word length = 24 bit
Word length not indicated (default )
20bits
22bits
23bits
24bits
21bits
Reserved
Initiate Request
Mode
Request Short
Audio & ARC
Initiation
Performs sending of the request short audio descriptor and
request ARC initiation.
Request ARC
Initiation
Sends only the request ARC initiation.
No Request
CEC exchange is not performed.
