Chapter 5 Signal Generate
125
GBD Color Precision
8bit
10bit
12bit
Format Flag = Vertices/Facets
GBD Color Space
ITU-R BT.709(using RGB)
xvYCC601(IEC 61966-2-4-SD)(using YCbCr)
xvYCC709(IEC 61966-2-4-HD)(using YCbCr)
XYZ
Format Flag = Range
GBD Color Space
Reserved
RGB expression of xvYCC601
RGB expression of xvYCC709
Format Flag = Vertices/Facets
Facet Mode
0 or 1
Number Vertces H
XX H
Number Vertices L
XX H
Packed GBD Vertices
Data
±X.XX
Format Flag = Range
Packed Range Data
±X.XX
Gamut Rsv pb0
XX H
