174
9.3-3
[Other than CEC Switch]
Send <Give Physical Address> to the DUT.
[CEC Switch]
Broadcast <Routing Information> [1.0.0.0] to the
DUT.
DUT does not return ACK for the header block and
all message blocks of the message to be broadcast.
[Other than CEC Switch]
DUT broadcasts <Report Physical Address>
and tries to resend.
[CEC Switch]
DUT broadcasts <Routing Information> and
tries to resend.
9.3-4
[Other than CEC Switch]
Send <Abort> to the DUT.
[CEC Switch]
Broadcast <Routing Information> [1.0.0.0] to the
DUT.
Set the bus to low impedance while the DUT is
sending high impedance.
[Other than CEC Switch]
DUT sends <Feature Abort> and tries to
resend.
[CEC Switch]
DUT broadcasts <Routing Information> and
tries to resend.
9.4-1
Send <Active Source> without a parameter to the
DUT.
DUT ignores the message.
9.4-2
[Other than CEC Switch]
Send <Abort> with an added data block to the DUT.
[CEC Switch]
Send <Routing Information> with an added data
block to the DUT.
DUT ignores the added data block and
replies to the message as usual.
9.5-1
Send <Abort> with a corrupt information bit 3.
Send <Abort> with a corrupt information bit 0.
Send <Abort> with a corrupt information bit 5.
Send <Abort> with a corrupt information bit 6.
Send <Abort> with a corrupt information bit 7.
DUT does not send <Feature Abort>.
9.6-1
Send <Abort> to the DUT.
Forcibly set the CEC line of the 0.8 ms period
after 3.5 ms to Low.
DUT sends <Feature Abort>.
When DUT detects low, arbitration is lost and
the sending of the current message stops.
DUT resends leaving an interval of at least 5
nominal data bits.
9.6-2
Send <Abort> to the DUT.
Send 0 on the bus while the DUT is sending 1 in the
source address bit.
DUT sends <Feature Abort>.
When the DUT detects that the bus is low for
the source address bit, it stops sending the
current message.
DUT resends leaving an interval of at least 5
nominal data bits.
9.7-1
Send <Abort> to the DUT.
DUT sends <Feature Abort>.
DUT leaves an interval of at least 5 nominal
data bits before attempting to send the
message.
9.7-2
Execute One Touch Play (Remote Control Pass
Through) with the DUT.
After sending the first message, the DUT
waits for at least a 7-nominal data bit period
before sending the next message.
