232
11.3.1-5
Connect an output of the DUT to the an input of the
VA-1842, and an input of the DUT to an output of the
VA-1842.
Check that the output of the DUT is at position 1.
Broadcast <Routing Change>[0.0.0.0][1.0.0.0]
Broadcasts <Routing Information> [1.1.0.0].
11.3.1-6
Connect an output of the DUT to the an input of the
VA-1842, and an input of the DUT to an output of the
VA-1842.
Check that the output of the DUT is at position 1.
Broadcast <Routing Information> [1.0.0.0].
Broadcasts <Routing Information> [1.1.0.0].
11.3.2-1
Connect an output of the DUT to the an input of the
VA-1842, and an input of the DUT to an output of the
VA-1842.
Check that the output of the DUT is at position 1.
Switch to position 2.
Broadcasts <Routing Change> [1.1.0.0]
[1.2.0.0].
