Chapter 4 Source ANALYSIS
37
IEEE Registration ID = 000C03 H
HDMI_Video_Format
no video format
Extended resolution format
3D format
Reserved
HDMI_Video_Format = Extended resolution format
HDMI_VIC
4Kx2K 29.97/30Hz
4Kx2K 25Hz
4Kx2K 23.98/24Hz
4Kx2K 24Hz(SMPTE)
Reserved
HDMI_Video_Format = 3D format
3D_Structure
Frame packing
Field alternative
Line alternative
Side-by-Side(Full)
L + depth
L + depth + graphics + graphics-depth
Top-and-Bottom
Side-by-Side(Half)
Reserved
3D_Meta_present
0H or 1H
3D_Structure = side-by-side(half)
3D_Ext_Data
Horizontal Odd/Left Odd/Right
Horizontal Odd/Left Even/Right
Horizontal Even/Left Odd/Right
Horizontal Even/Left Even/Right
Quincunx Odd/Left Odd/Right
Quincunx Odd/Left Even/Right
Quincunx Even/Left Odd/Right
Quincunx Even/Left Even/Right
Reserved
3D_Meta_present = 1H
3D_Metadata_type
XX H
3D_Metadata_Length
XX H
3D_Metadata_1~20
XX H
IEEE Registration ID = C45DD8 H
Version
XX
3D_Valid
0H or 1H
3D_Valid = 1
3D_F_Structure
Frame packing
Field alternative
Line alternative
Side-by-Side(Full)
L + depth
L + depth + graphics + graphics-depth
