Affected Gamut Seq Num
XX H
Current Gamut Seq Num
XX H
Packet Seq
Intermediate packet in sequence
First packet in sequence
Last packet in sequence
Only packet in sequence
GBD profile = P1 and Packet Seq = First packet in sequence
GBD Length H
XX H
GBD Length L
XX H
Checksum
XX H
Format Flag
Vertices/Facets
Range
GBD Color Precision
8bit
10bit
12bit
Format Flag = Vertices/Facets
GBD Color Space
ITU-R BT.709(using RGB)
xvYCC601(IEC 61966-2-4-SD)(using YCbCr)
xvYCC709(IEC 61966-2-4-HD)(using YCbCr)
XYZ
Format Flag = Range
GBD Color Space
Reserved
RGB expression of xvYCC601
RGB expression of xvYCC709
Reserved
Format Flag = Vertices/Facets
Facet Mode
0 or 1
Number Vertices H
XX H
Number Vertices L
XX H
Packed GBD Vertices
Data
±X.XX
Format Flag = Range
Packed Range Data
±X.XX
Gamut Rsv pb0
XX H
