ASTRO VA-1842 - Page 66

50
44.1kHz
48kHz
88.2kHz ( - HDMI Original )
96kHz ( - HDMI Original )
176.4kHz ( - HDMI Original )
192kHz ( - HDMI Original )
768kHz
Reserved
Clock accuracy
Level 2, ±1000ppm (default)
Level 3, variable pitch
Level 1, ±50ppm - high accuracy
Reserved
Maximum sample length
20bits
24bits
Sample word length
Maximum audio sample word length = 20 bit
Word length not indicated (default )
16bits
18bits
19bits
20bits
17bits
Reserved
Maximum audio sample word length = 24 bit
Word length not indicated (default )
20bits
22bits
23bits
24bits
21bits
Reserved
Rsv of Data
CSB Repetition Period
NO ERROR
ERROR
Audio FIFO ERROR
NO ERROR
ERROR
AudioPLL Lock ERROR
NO ERROR
ERROR
