User's Manual 492 Document #: LTRT-42060
Mediant 2600 E-SBC
CDR Field Name Description Format
RedirectURINum
Redirection URI String of up to 41 characters
RedirectURINumBeforeMap
Redirect URI number before manipulation String of up to 41 characters
TxSigIPDiffServ
Signaling IP DiffServ String of up to 15 characters
IPGroup
IP Group ID and name String of up to 40 characters
SrdId
SRD ID and name String of up to 29 characters
SIPInterfaceId
SIP Interface ID String of up to 15 characters
ProxySetId
Proxy Set ID String of up to 15 characters
IpProfileId
IP Profile ID and name String of up to 34 characters
MediaRealmId
Media Realm ID and name String of up to 55 characters
DirectMedia
Direct media or traversing SBC:
ï‚§ "yes"
ï‚§ "no"
String
SIPTrmReason
SIP call termination reason (BYE,
CANCEL, or SIP error codes, e.g., 404)
String of up to 12 characters.
SipTermDesc
Description of SIP termination reason:
ï‚§ SIP Reason header, if exists, for
example: SIP ;cause=200 ;text="Call
completed elsewhere".
ï‚§ If no SIP Reason header exists, the
description is taken from the reason
text, if exists, of the SIP response
code, for example: "417 Unknown
Resource-Priority".
ï‚§ If no reason text exists in the SIP
response code, the description is
taken from an internal SIP response
mapping mechanism. For example, if
the device receives a SIP response
"422", it sends in the CDR "422
Session Interval Too Small method" as
the description.
String of up to 26 characters
Caller
Name of caller String of up to 36 characters
Callee
Name of called party String of up to 36 characters
Below shows an example of an SBC signaling CDR sent at the end of a call (call was
terminated normally):
[S=40] |SBCReportType |EPTyp |SIPCallId |SessionId |Orig |SourceIp
|SourcePort |DestIp |DestPort |TransportType |SrcURI
|SrcURIBeforeMap |DstURI |DstURIBeforeMap |Durat |TrmSd |TrmReason
|TrmReasonCategory |SetupTime |ConnectTime |ReleaseTime
|RedirectReason |RedirectURINum |RedirectURINumBeforeMap
|TxSigIPDiffServ|IPGroup (description) |SrdId (name)
|SIPInterfaceId |ProxySetId |IpProfileId (name) |MediaRealmId
(name) |DirectMedia |SIPTrmReason |SIPTermDesc |Caller |Callee
[S=41] |CALL_END |SBC |20767593291410201017029@10.33.45.80
|1871197419|LCL |10.33.45.80 |5060 |10.33.45.72 |5060 |UDP
|9001@10.8.8.10 |9001@10.8.8.10 |6001@10.33.45.80
