AudioCodes Mediant 2600 User Manual

User's Manual 44 Document #: LTRT-42060
Mediant 2600 E-SBC
If you enter an invalid parameter value (e.g., not in the range of permitted values) and then
click Submit, a message box appears notifying you of the invalid value. In addition, the
parameter value reverts to its previous value and is highlighted in red, as shown in the
figure below:
Figure 6-9: Value Reverts to Previous Valid Value
6.1.6.4 Working with Tables
Many of the Web configuration pages provide tables for configuring various functionalities
of the device. The figure below and subsequent table describe the areas of a typical
configuration table:
Figure 6-10: Displayed Details Pane
Table 6-3: Enhanced Table Design Description
Item # Button
1 Add
Adds a new index entry row to the table. When you click this button, a
dialog box appears with parameters for configuring the new entry.
When you have completed configuration, click the Submit button in
the dialog box to add it to the table.
2 Edit
Edits the selected row.
3 Delete
Removes the selected row from the table. When you click this button,
a confirmation box appears requesting you to confirm deletion. Click
Delete to accept deletion.
