AudioCodes Mediant 2600 - Assigning Cost Groups to Routing Rules

User's Manual 228 Document #: LTRT-42060
Mediant 2600 E-SBC
Table 15-10: Time Band Table Description
Parameter Description
Index
CLI: timeband-index
[CostGroupTimebands_Timeba
ndIndex]
Defines an index number for the new table record.
Note: Each table row must be configured with a unique index.
Start Time
CLI: start-time
[CostGroupTimebands_StartTi
me]
Defines the day and time of day from when this time band is
applicable. The format is DDD:hh:mm, where:
 DDD is the day of the week, represented by the first three
letters of the day in upper case (i.e., SUN, MON, TUE, WED,
THU, FRI, or SAT).
 hh and mm denote the time of day, where hh is the hour (00-
23) and mm the minutes (00-59)
For example, SAT:22:00 denotes Saturday at 10 pm.
End Time
CLI: end-time
[CostGroupTimebands_EndTi
me]
Defines the day and time of day until when this time band is
applicable. For a description of the valid values, see the
parameter above.
Connection Cost
CLI: connection-cost
[CostGroupTimebands_Conne
ctionCost]
Defines the call connection cost during this time band. This is
added as a fixed charge to the call.
The valid value range is 0-65533. The default is 0.
Note: The entered value must be a whole number (i.e., not a
decimal).
Minute Cost
CLI: minute-cost
[CostGroupTimebands_Minute
Cost]
Defines the call cost per minute charge during this timeband.
The valid value range is 0-65533. The default is 0.
Note: The entered value must be a whole number (i.e., not a
decimal).
15.5.2.4 Assigning Cost Groups to Routing Rules
To use your configured Cost Groups, you need to assign them to routing rules:
 SBC application: IP-to-IP Routing table - see Configuring SBC IP-to-IP Routing Rules
on page
368
