AudioCodes Mediant 2600 User Manual

Version 6.8 73 Mediant 2600 E-SBC
User's Manual 8. SNMP-Based Management
Parameter Description
Community String - Read / Write
configure system > snmp > rw-
community-string
[SNMPReadWriteCommunityString_x]
Defines a read-write SNMP community string. Up to five
read-write community strings can be configured.
The valid value is a string of up to 19 characters that can
include only the following:
 Upper- and lower-case letters (a to z, and A to Z)
 Numbers (0 to 9)
 Hyphen (-)
 Underline (_)
For example, "Private-comm_string1".
The default is "private".
Trap Community String
configure system > snmp trap >
community-string
[SNMPTrapCommunityString]
Defines the community string for SNMP traps.
The valid value is a string of up to 19 characters that can
include only the following:
 Upper- and lower-case letters (a to z, and A to Z)
 Numbers (0 to 9)
 Hyphen (-)
 Underline (_)
For example, "Trap-comm_string1".
The default is "trapuser".
8.2 Configuring SNMP Trap Destinations
The SNMP Trap Destinations page allows you to configure up to five SNMP trap
managers. You can associate a trap destination with SNMPv2 users and specific SNMPv3
users. Associating a trap destination with SNMPv3 users sends encrypted and
authenticated traps to the SNMPv3 destination. By default, traps are sent unencrypted
using SNMPv2.
 To configure SNMP trap destinations:
1. Open the SNMP Trap Destinations page (Configuration tab > System menu >
Management > SNMP > SNMP Trap Destinations).
Figure 8-1: SNMP Trap Destinations Page
2. Configure the SNMP trap manager parameters according to the table below.
3. Select the check box corresponding to the SNMP Manager that you wish to enable.
4. Click Submit.
