Version 6.8 25 Mediant 2600 E-SBC
User's Manual 3. Default OAMP IP Address
3 Default OAMP IP Address
The device is shipped with a factory default IP address for operations, administration,
maintenance, and provisioning (OAMP), through its VoIP LAN interface. You can use this
address to initially access the device from any of its management tools (embedded Web
server, EMS, or Telnet/SSH). You can also access the device through the console CLI, by
connecting the device's serial (RS-232) port to a PC.
The table below lists the device's default IP address.
Table 3-1: Default VoIP LAN IP Address for OAMP
IP Address Value
Application Type OAMP + Media + Control
IP Address 192.168.0.2 - this IP address is assigned to the first Ethernet Port
Group (top-left ports 1 & 2)
Prefix Length 255.255.255.0 (24)
Default Gateway 192.168.0.1
Underlying Device 1
Interface Name "O+M+C"
