SIP User's Manual 204 Document #: LTRT-12801
MP-500 MSBG
Parameter Description
Web: Src. Trunk Group ID
EMS: Source Trunk Group ID
[PREFIX_SrcTrunkGroupID]
The source Hunt Group ID of the call.
The range is 1-99.
Notes:
 If this parameter is not required in the routing rule, leave the field
empty.
 To denote any Hunt Group, you can enter the asterisk (*) symbol.
Web: Dest. Phone Prefix
EMS: Destination Phone
Prefix
[PREFIX_DestinationPrefix]
Called telephone number prefix.
The prefix can include up to 50 digits.
Note: The destination phone prefix can be a single digit or a range of
digits. For available notations representing multiple numbers/digits,
refer to ''Dialing Plan Notation for Routing and Manipulation'' on page
451.
Web/EMS: Source Phone
Prefix
[PREFIX_SourcePrefix]
Calling telephone number prefix.
The prefix can include up to 50 digits.
Note: The source phone prefix can be a single digit or a range of
digits. For available notations representing multiple numbers/digits,
refer to ''Dialing Plan Notation for Routing and Manipulation'' on page
451.
All Tel calls matching all or any combination of the above routing rules are subsequently sent to the
destination IP address defined below.
Notes:
 For alternative routing, additional entries of the same prefixes can be configured.
 For notations representing multiple numbers, refer to ''Dialing Plan Notation for Routing and
Manipulation'' on page 451.
Web: Dest. IP Address
EMS: Address
[PREFIX_DestAddress]
The destination IP address (in dotted-decimal notation or FQDN) to
where the call is sent. If an FQDN is used (e.g., domain.com), DNS
resolution is performed according to the parameter DNSQueryType.
Notes:
 If you define a destination IP Group, then this IP address is not
used for routing and therefore, not required.
 To discard outgoing IP calls of a specific Tel-to-IP routing rule,
enter 0.0.0.0. For example, if you want to prohibit dialing of
international calls, then in the 'Dest Phone Prefix' field, enter 00
and in the 'Dest IP Address' field, enter 0.0.0.0.
 For routing calls between phones connected to the device (i.e.,
local routing), enter the device's IP address.
 When the device's IP address is unknown (e.g., when DHCP is
used), enter IP address 127.0.0.1.
 When using domain names, you must enter a DNS server IP
address or alternatively, define these names in the 'Internal DNS
Table' (refer to ''Configuring the Internal DNS Table'' on page
208).
 If the string 'ENUM' is specified for the destination IP address, an
ENUM query containing the destination phone number is sent to
the DNS server. The ENUM reply includes a SIP URI used as the
Request-URI in the outgoing INVITE and for routing (if a Proxy is
not used).
 The IP address can include wildcards. The 'x' wildcard is used to
To Next Page
