Version 5.8 233 October 2009
SIP User's Manual 3. Web-Based Management
Parameter Description
 [3] AES-128
 [4] AES-192
 [5] AES-256
Authentication Key
[SNMPUsers_AuthKey]
Authentication key. Keys can be entered in the form of a text
password or long hex string. Keys are always persisted as long hex
strings and keys are localized.
Privacy Key
[SNMPUsers_PrivKey]
Privacy key. Keys can be entered in the form of a text password or
long hex string. Keys are always persisted as long hex strings and
keys are localized.
Group
[SNMPUsers_Group]
The group with which the SNMP v3 user is associated.
 [0] Read-Only (default)
 [1] Read-Write
 [2] Trap
Note: All groups can be used to send traps.
3.5.1.1.4 Configuring SNMP Trusted Managers
The 'SNMP Trusted Managers' page allows you to configure up to five SNMP Trusted
Managers, based on IP addresses. By default, the SNMP agent accepts SNMP Get and
Set requests from any IP address, as long as the correct community string is used in the
request. Security can be enhanced by using Trusted Managers, which is an IP address
from which the SNMP agent accepts and processes SNMP requests.
¾ To configure the SNMP Trusted Managers:
1. Access the 'Management Settings' page, as described in ''Configuring the
Management Settings'' on page 228.
2. In the 'SNMP
Trusted Managers' field, click the right-pointing arrow
button; the
'SNMP Trusted Managers' page appears.
Figure 3-182: SNMP Trusted Managers
3. Select the check box corresponding to the SNMP Trusted Manager that you want to
enable and for whom you want to define an IP address.
4. Define an IP address in dotted-decimal notation.
5. Click the Submit button to apply your changes.
6. To save the changes, refer to ''Saving Configuration'' on page 237.
