SIP User's Manual 180 Document #: LTRT-12801
MP-500 MSBG
3.4.5.8 Configuring the SBC Tables
The SBC submenu provides configuration page for configuring the SBC application. This
submenu includes the following items:
îš„ General Settings (refer to ''Configuring General SBC Settings'' on page 180)
îš„ SRD Ta
ble (refer to ''Configuring the Signaling Routing Domain Table'' on page 180)
îš„ SIP Interface Table (refe
r to ''Configuring the SIP Interface Table'' on page 182)
îš„ Cla
ssification Table (refer to ''Configuring the Classification Table'' on page 184)
îš„ IP2IP Routing Table (refe
r to ''Configuring the SBC IP2IP Routing Table'' on page 186)
îš„ IP to IP Inbound Manip
ulation (refer to ''Configuring the IP to IP Inbound Manipulation
Table'' on page 190)
îš„ IP to IP Outbound Ma
nipulation (refer to ''Configuring the IP to IP Outbound
Manipulation Table'' on page 193)
Note: The SBC submenu appears only if the SBC application has been enabled
(refer to ''Enabling Applications'' on page 142).
3.4.5.8.1 Configuring General SBC Settings
The 'General Settings' page allows you to configure fundamental SBC parameters such as
the WAN IP address and the transcoding method. For a description of these parameters,
refer to ''SBC Parameters'' on page 383.
¾ To configure the general SBC parameters:
1. Open the 'General Settings' page (Configuration tab > Protocol Configuration menu
> SBC submenu > General Settings page item).
Figure 3-155: General Settings Page
2. Configure the parameters as required.
3. Click the Submit button to save your changes.
4. To save the changes to flash memory, refer to ''Saving Configuration'' on page 237.
