Version 5.8 383 October 2009
SIP User's Manual 6. Configuration Parameters Reference
Parameter Description
Web/EMS: RTP DSCP for MLPP
Flash
[MLPPFlashRTPDSCP]
Defines the RTP DSCP for MLPP Flash precedence call level.
The valid range is -1 to 63. The default is -1.
Note: If set to -1, the DiffServ value is taken from the global
parameter PremiumServiceClassMediaDiffServ or as defined for
IP Profiles per call (using the parameter IPProfile).
Web/EMS: RTP DSCP for MLPP
Flash Override
[MLPPFlashOverRTPDSCP]
Defines the RTP DSCP for MLPP Flash-Override precedence
call level.
The valid range is -1 to 63. The default is -1.
Note: If set to -1, the DiffServ value is taken from the global
parameter PremiumServiceClassMediaDiffServ or as defined for
IP Profiles per call (using the parameter IPProfile).
Web/EMS: RTP DSCP for MLPP
Flash-Override-Override
[MLPPFlashOverOverRTPDSCP]
Defines the RTP DSCP for MLPP Flash-Override-Override
precedence call level.
The valid range is -1 to 63. The default is -1.
Note: If set to -1, the DiffServ value is taken from the global
parameter PremiumServiceClassMediaDiffServ or as defined for
IP Profiles per call (using the parameter IPProfile).
EMS: E911 MLPP Behavior
[E911MLPPBehavior]
Defines the E911(or Emergency Telecommunication Services -
ETS) MLPP Preemption mode:
• [0] Standard Mode - ETS calls have the highest priority and
preempt any MLPP call (default).
• [1] Treat as routine mode - ETS calls are handled as routine
calls.
Web/EMS: Precedence Ringing
Type
[PrecedenceRingingType]
Defines the index of the Precedence Ringing tone in the Call
Progress Tones (CPT) file. This tone is used when the
parameter CallPriorityMode is set to 1 and a Precedence call is
received from the IP side.
The valid range is -1 to 16. The default value is -1 (i.e., plays
standard Ringing tone).
