Version 5.8 153 October 2009
SIP User's Manual 3. Web-Based Management
Notes:
• By default, if you disable the use of a proxy (i.e., IsProxyUsed is set to 0),
then only one IP Group is defined (and working with multiple IP Groups is
not valid).
• If different SRDs are configured in the ‘IP Group’ and ‘Proxy Set’ tables,
the SRD defined for the Proxy Set takes precedence.
• You can also configure the IP Groups table using the ini file table
parameter IPGroup (refer to ''SIP Configuration Parameters'' on page
318).
¾ To configure IP Groups:
1. Open the 'IP Group Table' page (Configuration tab > Protocol Configuration menu
> Proxies/IpGroups/Registration submenu > IP Group Table page item).
Figure 3-142: IP Group Table
2. Configure the IP group parameters according to the table below.
3. Click the Submit button to save your changes.
4. To save the changes to flash memory, refer to ''Saving Configuration'' on page 237.
