Version 5.8 377 October 2009
SIP User's Manual 6. Configuration Parameters Reference
Parameter Description
EMS: Blind Transfer Disconnect
Timeout
[BlindTransferDisconnectTimeout]
Defines the duration (in milliseconds) for which the device
waits for a disconnection from the Tel side after the Blind
Transfer Code (KeyBlindTransfer) has been identified. When
this timer expires, a SIP REFER message is sent toward the
IP side. If this parameter is set to 0, the REFER message is
immediately sent.
The valid range is 0 to 1,000,000. The default is 0.
6.8.7 Three-Way Conferencing Parameters
The three-way conferencing parameters are described in the table below.
Table 6-36: Three-Way Conferencing Parameters
Parameter Description
Web: Enable 3-Way
Conference
EMS: Enable 3 Wa
[Enable3WayConference]
Enables or disables the 3-Way Conference feature.
[0] Disable = Disable (default)
[1] Enable = Enables 3-way conferencing
Note: For this parameter to take effect, a device reset is required.
Web: 3-Way Conference
Mode
EMS: 3 Way Mode
[3WayConferenceMode]
Defines the mode of operation when the 3-Way Conference feature is
used.
[0] AudioCodes Media Server = The Conference-initiating INVITE
(sent by the device), uses the ConferenceID concatenated with a
unique identifier as the Request-URI. This same Request-URI is set
as the Refer-To header value in the REFER messages that are sent
to the two remote parties. This conference mode is used when
operating with AudioCodes IPMedia conferencing server. (Default)
[1] Non-AudioCodes Media Server = The Conference-initiating
INVITE (sent by the device) uses only the ConferenceID as the
Request-URI. The conference server sets the Contact header of the
200 OK response to the actual unique identifier (Conference URI) to
be used by the participants. This Conference URI is then included
(by the device) in the Refer-To header value in the REFER
messages sent by the device to the remote parties. The remote
parties join the conference by sending INVITE messages to the
conference using this conference URI.
Notes:
This parameter is applicable only to FXS interfaces.
When using an external conference server (i.e., options [0] or [1]),
more than one three-way conference may be supported (up to six).
Web: Establish
Conference Code
EMS: Establish Cod
[ConferenceCode]
Defines the digit pattern, which upon detection, generates the
Conference-initiating INVITE when 3-way conferencing is enabled
(Enable3WayConference is set to 1).
The valid range is a 25-character string. The default is “!” (Hook-Flash).
