SIP User's Manual 60 Document #: LTRT-12801
MP-500 MSBG
Table 3-6: Multiple Interface Table Parameters Description
Parameter Description
Table parameters
Index Index of each interface.
The range is 0 to 15.
Note: Each interface index must be unique.
Web: Application Type
EMS: Application Types
[InterfaceTable_ApplicationTypes]
Types of applications that are allowed on the specific
interface.
 [0] OAMP = Only Operations, Administration, Maintenance
and Provisioning (OAMP) applications (e.g., Web, Telnet,
SSH, and SNMP) are allowed on the interface.
 [1] Media = Only Media (i.e., RTP streams of voice) is
allowed on the interface.
 [2] Control = Only Call Control applications (e.g., SIP) are
allowed on the interface.
 [3] OAMP + Media = Only OAMP and Media applications
are allowed on the interface.
 [4] OAMP + Control = Only OAMP and Call Control
applications are allowed on the interface.
 [5] Media + Control = Only Media and Call Control
applications are allowed on the interface.
 [6] OAMP + Media + Control = All application types are
allowed on the interface.
Notes:
 For Voice and Data functionality: Do not change the
Application Type for any of the selected interfaces (i.e.,
leave them as "OAMP + Media + Control" and "Data").
 A single OAMP interface (and only one) must be
configured. This OAMP interface can be combined with
Media and Control.
 At least one interface with Media and at least one interface
with Control must be configured.
 Multiple interfaces for Media, Control, and Media and
Control can be configured.
 At least one IPv4 interface with Control must be
configured. This can be combined with OAMP and Media.
 At least one IPv4 interface with Media must be configured.
This can be combined with OAMP and Control.
Web/EMS: IP Address
[InterfaceTable_IPAddres]
The IPv4 IP address in dotted-decimal notation.
Note: Each interface must be assigned a unique IP address.
Web/EMS: Prefix Length
[InterfaceTable_PrefixLength]
Defines the Classless Inter-Domain Routing (CIDR)-style
representation of a dotted decimal subnet notation. The
CIDR-style representation uses a suffix indicating the number
of bits which are set in the dotted decimal format (e.g.
192.168.0.0/16 is synonymous with 192.168.0.0 and a subnet
of 255.255.0.0. Defines the number of ‘1’ bits in the subnet
mask (i.e., replaces the standard dotted-decimal
representation of the subnet mask for IPv4 interfaces). For
example: A subnet mask of 255.0.0.0 is represented by a
