Example 3 - One interface exclusively for management (OAMP applications) and two
others for Call Control and RTP (CONTROL and MEDIA applications):
The Multiple Interface table is configured with four interfaces. One is exclusively for
Management and the two are for Call Control and RTP Media applications. Two of them are
IPv4 interfaces:
Table 10-13: Multiple Interface Table - Example 3
Index Application Interface IP Address
Prefix
Length
Default
Gateway
VLAN
ID
Interface
Name
0 OAMP IPv4 192.168.85.14 16 0.0.0.0 1 Mgmt
1
Media &
Control
IPv4 200.200.85.14 24 200.200.85.1 201 CntrlMedia1
2
Media &
Control
IPv4 200.200.86.14 24 0.0.0.0 202 CntrlMedia2
VLANs are required. The 'Native' VLAN ID is the same VLAN ID as the AudioCodes
Management interface (index 0). One routing rule is required to allow remote management
from a host in 176.85.49.0/24.
Table 10-14: Routing Table - Example 3
Destination Prefix Length Subnet Mask Gateway Interface Metric
176.85.49.0 24
192.168.0.1 0 1
All other parameters are set to their respective default values. The ini file matching this
configuration can be written as follows:
; Interface Table Configuration:
[InterfaceTable]
FORMAT InterfaceTable_Index = InterfaceTable_ApplicationTypes,
InterfaceTable_InterfaceMode, InterfaceTable_IPAddress,
InterfaceTable_PrefixLength, InterfaceTable_Gateway,
InterfaceTable_VlanID, InterfaceTable_InterfaceName;
InterfaceTable 0 = 0, 10, 192.168.85.14, 16, 0.0.0.0, 1, Mgmt;
InterfaceTable 1 = 5, 10, 200.200.85.14, 24, 200.200.85.1, 201,
CntrlMedia1;
InterfaceTable 2 = 5, 10, 200.200.86.14, 24, 0.0.0.0, 202, CntrlMedia2;
[\InterfaceTable]
; VLAN related parameters:
VlanMode = 1
VlanNativeVlanId = 1
; Routing Table Configuration:
RoutingTableDestinationsColumn = 176.85.49.0
RoutingTableDestinationPrefixLensColumn = 24
RoutingTableGatewaysColumn = 192.168.0.1
RoutingTableInterfacesColumn = 0
RoutingTableHopsCountColumn = 1
