Version 5.8 283 October 2009
SIP User's Manual 5. Element Management System (EMS)
5.5 Provisioning SIP MLPP Parameters
This section describes how to configure the MLPP (Multi-Level Precedence and
Preemption) parameters using the EMS.
¾ To configure the MLPP parameters:
1. In the MG Tree, select the device.
2. Select the Advanced tab; the 'SIP Advanced Configuration' frame appears.
3. Select the MLPP tab; the following screen appears:
4. Configure the MLPP parameters as required.
Note: If the following RTP DSCP parameters are set to “-1” (i.e., Not Configured,
Default), the DiffServ value is set with the PremiumServiceClassMediaDiffserv
global gateway parameter, or by using IP Profiles: MLPPRoutineRTPDSCP,
MLPPPriorityRTPDSCP, MLPPImmediateRTPDSCP, MLPPFlashRTPDSCP,
MLPPFlashOverRTPDSCP, MLPPFlashOverOverRTPDSCP,
MLPPNormalizedServiceDomain.
