AudioCodes mediapack MP-500 User Manual

SIP User's Manual 296 Document #: LTRT-12801
MP-500 MSBG
Table 6-4: QoS Parameters
Parameter Description
Layer-2 Class Of Service Parameters (VLAN Tag Priority Field)
DiffServ Table
[DiffServToVlanPriority]
This ini file table parameter allows you to configure
VLAN tag priorities.The format of this ini file is as follows:
[ DiffServToVlanPriority ]
FORMAT DiffServToVlanPriority_Index =
DiffServToVlanPriority_DiffServ,
DiffServToVlanPriority_VlanPriority;
[ \DiffServToVlanPriority ]
For example:
DiffServToVlanPriority 0 = 48, 7;
DiffServToVlanPriority 1 = 46, 6;
DiffServToVlanPriority 2 = 40, 6;
DiffServToVlanPriority 3 = 26, 4;
DiffServToVlanPriority 4 = 10, 2;
Notes:
 You can configure up to 64 VLAN tag priorities (i.e.,
indices 0-63).
 The valid range of the parameter DiffServ is 0-63.
 The valid range of the parameter VlanPriority is 0-7.
Layer-3 Class of Service (TOS/DiffServ) Parameters
For detailed information on IP QoS via Differentiated Services, refer to ''IP QoS via Differentiated
Services (DiffServ)'' on page 546.
Web: Media Premium QoS
EMS: Premium Service Class Media Diff
Serv
[PremiumServiceClassMediaDiffServ]
Defines the DiffServ value for Premium Media CoS
content (only if IPDiffServ is not set in the selected IP
Profile).
The valid range is 0 to 63. The default value is 46.
Note: The value for the Premium Control DiffServ is
determined by the following (according to priority):
 IPDiffServ value in the selected IP Profile.
 PremiumServiceClassMediaDiffServ.
Web: Control Premium QoS
EMS: Premium Service Class Control Diff
Serv
[PremiumServiceClassControlDiffServ]
Defines the DiffServ value for Premium Control CoS
content (only if ControlIPDiffserv is not set in the
selected IP Profile).
The valid range is 0 to 63. The default value is 40.
Note:
 The value for the Premium Control DiffServ is
determined by the following (according to priority):
9 ControlPDiffserv value in the selected IP Profile.
9 PremiumServiceClassControlDiffServ.
Web: Gold QoS
EMS: Gold Service Class Diff Serv
[GoldServiceClassDiffServ]
Defines the DiffServ value for the Gold CoS content.
The valid range is 0 to 63. The default value is 26.
Web: Bronze QoS
EMS: Bronze Service Class Diff Serv
[BronzeServiceClassDiffServ]
Defines the DiffServ value for the Bronze CoS content.
The valid range is 0 to 63. The default value is 10.
