SIP User's Manual 306 Document #: LTRT-12801
MP-500 MSBG
Parameter Description
Web: CDR Server IP
Address
EMS: IP Address of CDR
Server
[CDRSyslogServerIP]
Defines the destination IP address to where CDR logs are sent.
The default value is a null string, which causes CDR messages to be
sent with all Syslog messages to the Syslog server.
Note: The CDR messages are sent to UDP port 514 (default Syslog
port).
Web/EMS: CDR Report
Level
[CDRReportLevel]
Determines whether Call Detail Records (CDR) are sent to the Syslog
server and when they are sent.
 [0] None = CDRs are not used (default).
 [1] End Call = CDR is sent to the Syslog server at the end of each
call.
 [2] Start & End Call = CDR report is sent to Syslog at the start and
end of each call.
 [3] Connect & End Call = CDR report is sent to Syslog at connection
and at the end of each call.
 [4] Start & Connect & End Call = CDR report is sent to Syslog at the
start, at connection, and at the end of each call.
The CDR Syslog message complies with RFC 3161 and is identified by:
Facility = 17 (local1) and Severity = 6 (Informational).
Web/EMS: Debug Level
[GwDebugLevel]
Syslog debug logging level.
 [0] 0 = Debug is disabled (default).
 [1] 1 = Flow debugging is enabled.
 [2] 2 = Flow and device interface debugging are enabled.
 [3] 3 = Flow, device interface, and stack interface debugging are
enabled.
 [4] 4 = Flow, device interface, stack interface, and session manager
debugging are enabled.
 [5] 5 = Flow, device interface, stack interface, session manager, and
device interface expanded debugging are enabled.
Note: Usually set to 5 if debug traces are needed.
Web: Activity Types to
Report via Activity Log
Messages
[ActivityListToLog]
The Activity Log mechanism enables the device to send log messages
(to a Syslog server) for reporting certain types of Web operations
according to the below user-defined filters.
 [PVC] Parameters Value Change = Changes made on-the-fly to
parameters.
 [AFL] Auxiliary Files Loading = Loading of auxiliary files (e.g., via
'Certificate' page).
 [DR] Device Reset = Reset of device via the 'Maintenance Actions'
page.
 [FB] Flash Memory Burning = Burning of files or parameters to flash
(in 'Maintenance Actions' page).
 [SWU] Device Software Update = cmp file loading via the Software
Upgrade Wizard.
 [ARD] Access to Restricted Domains = Access to restricted domains,
which include the following Web pages:
9 (1) ini parameters (AdminPage)
9 (2) 'General Security Settings'
