Adding a new threshold
In a nutshell:
1. Click Devices in the sidebar.
2. In the Sites Tree pane select the stream.
3. In the right pane select the Thresholds tab.
4. If the Thresholds slider is OFF , click it to switch Thresholds to ON .
5. In the threshold definition area:
c. Click or to add a threshold before (to the left of) or after (to the right of) an existing
threshold.
d. Edit the threshold as desired. Refer to:
Changing a threshold’s name
Changing a threshold’s range
Setting a threshold’s False Alarm Filter
Setting Threshold Actions
6. Save changes by clicking .
You can define more thresholds in addition to the three thresholds the system creates by default. A new threshold
is always inserted in between two existing thresholds. It can be inserted anywhere between the very lowest and
very highest thresholds. The maximum number of thresholds for a data stream is eight thresholds.
To add a new threshold:
1. Determine where you want to insert the new threshold, and then in the threshold definition area
(Figure 55) click either or to add a threshold before (to the left of) or after (to the right
of) an existing threshold.
2. Edit the threshold as desired. Refer to:
Changing a threshold’s name
Changing a threshold’s range
Setting a threshold’s False Alarm Filter
Setting Threshold Actions
3. Save changes by clicking . The changes will go into effect the next time the device communicates with
the server.
