232 R5976924 PROJECTOR TOOLSET 16/04/2009

Table of Contents

Default Chapter5
- Table of Contents5
1 Basic Concepts11
- Introduction11
- About a Conﬁguration11
- About a Snapshot11
- About Storing Conﬁgurations and Snapshots11
2 Installation13
- General Requirements13
- Free Download of Projector Toolset14
- Projector Toolset Installation14
- Starting up16
- Manual Installation of a Device Plug-In19
- Uninstall Projector Toolset21
- About this Manual21
3 Menus23
- General23
- Menu and Button Bar23
- Main Window24
- Tool Tip24
- Short Cut Keys25
- Workspace Explorer25
- How to Adjust a Setting26
- About Projector Toolset26
- Module Details28
- Plug-In Details29
- Snapshot Management30
4 Preferences39
- Introduction39
- Start up the Preferences39
- Access Level40
- Software Appearance41
- Language Selection41
- Bug Report Setup44
- Logging45
- Workspace Selection46
5 Conﬁgurator49
- Introduction49
- Conﬁgurator Window49
- Create a New Conﬁguration49
- Add Projector to a Conﬁguration50
- Reconnect a Projector61
- Move Projector to a Group63
- Edit Projector Properties64
- Conﬁguration Preview66
- Conﬁguration Properties66
- Preview Layout Properties67
- Multiple Projector Selection72
6 Conﬁgurator, General Projector Settings75
- Start up75
- Control Interface77
- Basic Controls, Lamp ON/OFF77
- Basic Controls, Pause Setting78
- Basic Control, Text ON/OFF79
- Test Pattern Short Cuts79
- Test Patterns, Others80
- Advanced Controls81
- Maintenance93
  - Reset to Factory Defaults93
  - Reset Electronics94
7 Conﬁgurator, Projector Alignment Settings97
- Lens Control97
- Alignment Pattern99
- Gamma Adjustment100
- Individual Color Selection101
- Horizontal Keystone Correction101
- Blanking Adjustment102
- Scenergix104
8 Conﬁgurator, Projector Adjustment Settings115
- Native Resolution115
- Window and Source Selection116
- Conﬁguring an Input Slot118
- Status Input Window, Visible - Not Visible120
- Input Files121
- Image Settings140
- Layout Settings142
9 Conﬁgurator, Color Alignment157
- Ways to Set up Color Temperature157
- Color Space157
- Custom Color Space Set up158
- White Point Adjustment160
- Save Custom Settings164
- Preview Set up of the Color Diagram164
10 Conﬁgurator, Installation Settings167
- Image Orientation167
- Lamp Settings167
- Lamp Power Mode168
11 Conﬁgurator, Communication Settings171
- Network Settings171
- Serial Network Address174
- DMX Settings174
- Infrared Receivers176
12 Conﬁgurator, Warping179
- About Warping179
- Type of Warping Selection179
- Warp with Commands180
- Warp Via User Interface184
13 Conﬁgurator, Warp User Interface191
- About the Warp UI192
- Node Selection192
- About the Floater Menu193
- Increasing - Decreasing the Number of Nodes194
- Make Node Selection195
- Change Selection to New Active Node198
- Making an Adjustment Via Drag and Drop199
- Making an Adjustment Via the Floater Menu or Keyboard199
- Add a Hard Edge200
- Move a Hard Edge Line201
- Remove a Hard Edge202
- Show Hard Edge in Active Node Mode202
- Save Conﬁguration to File203
- Load a Conﬁguration in the Warp UI204
- Start up Cylindrical Warping205
- Indentation206
- Gradient207
- Fast Preview208
- Re-Size and Centering for Cylindrical Warping209
- Recover Warping Board210
- Preferences210
  - Background of the Grid210
  - Active Node Intersection211
  - Interpolation Node Intersection212
  - Hard Edges212
  - Color Selection213
14 Update Module217
- Introduction217
- Updating the Projector217
- Version Info219
15 Diagnostics Module221
- Introduction221
- Actual Mode221
- History Mode223
  - History Overview224
  - Set History Options224
16 Lens Calculator227
- Introduction227
- Launching the Lens Calculator227
- Functions of the Lens Calculator228
- Calculate Lens228
- Calculate a Lens229
- Calculate Distance230
- Calculate Screen230
17 Service Module233
- Introduction233
- Standard Maintenance233
- Services FLM Group234
  - Upgrade Projector234
Glossary237
Index239
