BD FocalPoint™ GS Imaging System Instrument User’s Manual
16
2.2 BD FocalPoint™ GS Review Station
The BD FocalPoint™ GS Review Station is designed for the desktop and allows the user to
perform a computer assisted slide review. It consists of a Main Window (monitor), specialized
guided screening software and an automated review microscope.
The BD FocalPoint™ GS Review Station components include the following:
• Monitor
• Keyboard and Mouse
• CPU
• Foot pedal (optional)
• Automated Microscope Stage
• Barcode Scanner
BD FocalPoint™ Slide Profiler produced slide information, FOV coordinates and cell images
from the central database are transferred to the BD FocalPoint™ GS Review Station. The
cytotechnologist uses the automated re-location capability of the BD FocalPoint™ GS Review
Station to evaluate the pre-selected FOVs.
2.2.1 BD FocalPoint™ Slide Profiler Slide Information
The BD FocalPoint™ Slide Profiler processes slides and transmits slide information data to a
central server that can be retrieved at the BD FocalPoint™ GS Review Station. When the
cytotechnologist reviews a slide at the BD FocalPoint™ GS Review Station the slide information
is presented. It is important to understand the significance of this information in the workflow
process.
Figure 2-2 illustrates the Slide information data as it appears at the BD FocalPoint™ GS Review
Station.
Figure 2-2 – Slide Information area
NOTE
The black and white, 20x magnification jpeg digital images that the
BD FocalPoint™ Slide Profiler provides are intended for relocation/
calibration purposes only and are not intended for the purpose of
interpretation.
