Bernina 990 - 17 Technical Data

Maintenance
17 Technical Data 109
Designation Value Unit
Maximum Speed 1200 Stitches per Minute
Needle System 130/705
Measurements without the Spool Pin (W × H × D) 675 × 420 × 245
(26.6 × 16.5 × 9.7)
mm
(in)
Measurements incl. Embroidery Module without
Spool Pin (W × H × D)
1175 × 420 × 635
46.3 × 16.5 × 25.0
mm
(in)
Weight of the Machine 19.2
(42.3)
kg
(lb)
Weight of the Embroidery Module 6.7
14.8
kg
(lb)
Energy Consumption 160 W
Input Voltage 100 – 240
50/60
V
Hz
WiFi Frequency Band
WiFi Protocol
2.4
802.11 b/g/n
GHz
Power Output (802.11b)
Power Output (802.11g)
Power Output (802.11n)
17.5
14.0
12.5
dBm
dBm
dBm
Laser Class
(according to IEC60825-1:2014)
Protection Class (Electrical Engineering) II
