Embroidery
11 Embroidery Screen 80
n Zoom In/Zoom Out
: Zoom view in or out.
n Default: Reset the view to the default.
Context Menu
You can tap and hold an object to open a context
menu with the following functions:
n Edit Text: Change selected text.
n Lock: Lock selected object for editing. The layer is
marked with the Lock
icon. You can unlock the
object by tapping the Lock
icon in the layer bar.
n Delete: Delete selected objects.
n Delete All: Delete all objects.
n Mirror Left/Right: Mirror the selected object on a
vertical axis.
n Mirror Up/Down: Mirror the selected object on a
horizontal axis.
n Select All: Select all objects.
11.1 Status Bar
The Status Bar displays the state of various functions.
Some functions can be set directly with the respective
status, e.g. the needle position or the laser. For other
functions, you can open the settings via the status
display, e.g. upper thread tension.
The color of the icon shows the current state of the
function.
n White: Default setting
n Blue: Active setting
n Yellow: Modified setting
n Red: Warning
WiFi, Time and Alarm
The WiFi
icon displays the WiFi connectivity, the
current time and alarm if active.
By tapping the icon, you open the settings for WiFi,
Time and the Alarm function. In the Settings, you can
switch the WiFi connection on or off or set up the WiFi
connection. [}see page45]
You can also set a reminder. [}see page44]
Upper Thread Tension
The Upper Thread Tension
status shows the
recommended upper thread tension for the selected
embroidery design.
You can modify the upper thread tension for the
selected embroidery design by tapping the status.
[}see page45]
Presser Foot
The Presser Foot
status shows the recommended
or selected presser foot.
You can open presser foot selection by tapping the
icon. In the presser foot selection, you can select the
attached presser foot and display details about the
presser foot. [}see page41]
Hoop
The Hoop
status displays the attached hoop. If no
hoop has been attached, the status shows the recom-
mended hoop for the selected embroidery design.
n White/Bue: Default and/or selected hoop.
n Yellow: Attached and recognized hoop.
n Red: Incompatible hoop or design does not fit
inside the hoop area.
You can select the attached hoop and display details
for the hoop by tapping the status. [}see page43]
Stitch Plate and Sewing Needle
The Stitch Plate and Sewing Needle
status
shows the selected needle and the attached stitch
plate. The attached stitch plate is automatically
recognized.
You can open the needle overview and select the
attached needle by tapping the icon. [}see page33]
Feed Dog
The Feed Dog
status shows the position of the
feed dog. In embroidery mode, the feed dog is lowered
automatically.
Bobbin Thread
The Bobbin Thread
status shows the fill capacity of
the lower thread bobbin.
n White: Good
n Yellow: Low or Empty
You can open the Bobbin Thread Status by tapping the
Bobbin Thread
icon. In the setting, the bobbin fill
capacity is shown and you can visualize the animation
and step-by-step instructions to insert the Bobbin Case.
TIP
Toggle the light on/off to make it easier to insert the
Bobbin Case when the Slide-on Table is attached.
Camera
The Camera
icon shows the status of the camera.
n White: Camera off.
n Yellow: Camera on.
n Red: Camera not available.
You can switch the camera on and off for a live image
of the embroidery area by tapping the icon. You can
only switch on the camera if a hoop is attached.
