Application Label Types
BBP
®
35/37 User’s Manual 126 Rev A
The In-Range Zone provides a visual element on the gauge to show when a system is entering
its optimal or detrimental value.
12. To add or change the size of the in-range zone, under In-Range Zone touch Start Value:
data field and enter the starting value for the range.
13. Under In-Range Zone, touch End Value: data field and enter the ending value for the
range.
Note: If you do not want an In-Range Zone, indicate a Start and End Value of 0
(zero).
14. To show the tick numbers on the scale, touch Show Numbers option box (if not already
selected).
To change the font size of the numbers in the gradient scale, with the Show Numbers option
box selected:
15. Touch the Font Size: data field and enter the desired point size of the font.
16. When ready, touch Finish .
