Printer Maintenance
BBP
®
35/37 User’s Manual 188 Rev A
11. Tuck the left edge of the upper guide underneath the cutter module carriage, on top of the
cut pad, aligning the hole on the right side with the empty screw hole.
12. Replace the upper guide screw into the screw hole and tighten.
13. Replace the cutter module by placing the flat surface of the collar against the carriage,
then inserting the cutter module into the carriage.
14. Insert the thumbscrew in the hole on the side of the cutter module carriage and tighten
until it clicks.
