3 - 18
Electrical parts and motors
Application of Di
sassembly
1
Disassembly
of
Power supply unit
1.
Remove the power lead wire assy .
1
.
2.
Remove the 2 screws
1
, and then remove the insulation plate
2
.
3.
Remove the screw
2
, and then remove the power plate spring
3
and the
power supply PCB assy.
4
.
1
2
1
4
2
3
2
Disassembly of Mai
n motor assy
1.
Remove the motor fan
1
.
2.
Remove the 2 screws
1
, and then remove the main motor
3
from the
motor holder
2
.
1
1
2
3
64
