3 - 22
Bobbin winder mechanism
Application of Di
sassembly
1
Removal of Bobbin base assy
1.
Remove the rubber ring
1
fro
m the bobbin winder wheel.
2.
Remove the bobbin base assy.
2
fr
om the bobbin winder assy.
3
.
3
2
1
1-1
Disassembly of Bobbin base assy
1.
Remove the bobbin thread cutter
holder
2
from the bobbin base assy.
1
.
*Key point
•
Be careful not to damage the 4 hooks
3
.
3.
Remove the NT lower threa
d cutter
4
from the bobbin base assy.
1
.
3
3
1
4
2
68
70
