5-136
Confidential
(6) Remove the six bind B M4x12 Taptite screws and the three cup S M3x6 Taptite screws.
(7) Remove the Frame L.
Fig. 5-185
Taptite, bind B M4x12
Taptite, bind B M4x12
Taptite cup S M3x6 SR
Under bar
Under bar
Frame L ASSY
