Brother DCP 8085DN

App. 1-41
Confidential
<WSW34>
Selector No. Function Setting and Specifications
1
I
3
Erasing time length of ICM tone
recorded preceding the tone
detection starting point in the
case of automatic line
disconnection due to no voice
signal received
(Not used.)
No. 1 2 3
0 0 0: 0 sec.
0 0 1: 1 sec.
0 1 0: 2 sec.
0 1 1: 3 sec.
1 0 0: 4 sec.
1 0 1: 5 sec.
1 1 0: 6 sec.
1 1 1: 7 sec.
4
5
No. of CNG cycles to be
detected
(when the line is connected via
the external telephone in the
external TAD mode or via the
machine in F/T mode)
(Not used.)
In the case of Selector 6=0 in WSW58.
No. 4 5
00: 0.5 (A)
01: 1 (B)
10: 1.5 (C)
11: 2 (D)
In the case of Selector 6=1 in WSW58.
No. 4 5
00: 2.5 (A)
01: 3 (B)
10: 3.5 (C)
11: 4 (D)
6
7
Number of DTMF tone signals
for inhibiting the detection of
CNG during external TAD
operation
(Not used.)
No. 6 7
00: 3
01: 2
10: 1
1 1: OFF
8 Not used.
