Brother DCP 8085DN

App. 1-42
Confidential
<WSW35>
<WSW36>
*ECP (Enhanced Capabilities Port)
Selector No. Function Setting and Specifications
1
I
4
Max. detection period of dial
tone/busy tone during recording
of ICM
(Not used.)
No. 1 2 3 4
0 0 0 0: No detection
0001: 1 sec.
0010: 2 sec.
0100: 4 sec.
|
1111: 15 sec.
5
I
8
Not used.
Selector No. Function Setting and Specifications
1 ECP mode* 0: ON 1: OFF
2
Recovery from Inactive PC
Interface
0: Disable 1: Enable
3 PC Power-off Recognition Time 0: Normal 1: Long
4 Not used.
5 Escape from phase C 0: Yes 1: No
6
I
8
Extension of incoming calling
signal (CI) frequency band
specified by selectors 1 through
4 on WSW14
No. 6 7 8
0 0 0: 0 (Ignored)
0 0 1: 4 (448 Hz)
0 1 0: 8 (244 Hz)
0 1 1: 12 (162 Hz)
1 0 0: 16 (122 Hz)
1 0 1: 20 (97 Hz)
1 1 0: 24 (81 Hz)
1 1 1: 28 (69 Hz)
Note:
• Selectors 2 and 3 will become operative if selectors 1 and 2 of WSW46 are set to
"monitor" the PC power ON/OFF state.
