Brother DCP 8085DN Service Manual

3-6
Confidential
Cooling Down
Wait for a while
The temperature of the
drum unit or toner cartridge
is too hot. The machine will
pause its current print job
and go into cooling down
mode. During the cooling
down mode, you will hear
the cooling fan running
while the LCD shows
Cooling Down, and Wait
for a while.
Make sure that you can hear the fan
in the machine spinning and that the
exhaust outlet is not blocked by
something.
If the fan is spinning, remove any
obstacles that surround the exhaust
outlet, and then leave the machine
turned on but do not use it for several
minutes.
3-20
Cover is Open The front cover is not
closed completely.
Close the front cover of the machine.
3-28
Cover is Open The fuser cover is not
closed completely or paper
was jammed in the back of
the machine when you
turned on the power.
Close the fuser cover of the machine.
Make sure paper is not jammed
inside the back of the machine, and
then close the fuser cover and press
Start.
3-16
Disconnected The other person or other
person’s fax machine
stopped the call.
Try to send or receive again.
3-69
Document Jam The document was not
inserted or fed properly, or
the document scanned
from the ADF was too
long.
Remove the jammed paper from the
ADF.
3-29
DR Mode in Use The machine is set to
Distinctive Ring mode. You
cannot change the
Receive Mode from
Manual to another mode.
Set Distinctive Ring to Off.
-
Drum Error The corona wire on the
drum unit needs to be
cleaned.
Clean the corona wire on the drum
unit.
3-21
3-23
The drum unit has reached
the end of its life.
Replace the drum unit.
Duplex Disabled The duplex tray is not
installed properly.
Remove the duplex tray and install it
again.
3-16
Fuser Error The temperature of fuser
unit does not rise at a
specified temperature
within specified time.
Do one of the following:
Turn the power switch off, wait a few
seconds, and then turn it on again.
Leave the machine for 15 minutes
with the power on.
3-17
3-19
3-20
3-21
3-37
The fuser unit is too hot.
Init Unable XX The machine has a
mechanical problem.
Perform processing with the error
code.
-
Jam Duplex The paper is jammed in
the duplex tray.
Remove the jammed paper from the
duplex tray.
3-16
Jam Rear The paper is jammed in
the back of the machine.
Remove the jammed paper from the
back of the machine.
3-24
Jam Inside The paper is jammed
inside the machine.
Remove the jammed paper from the
inside of the machine.
3-25
Error Message Type of Error Action
Refer
to

Brother DCP 8085DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	CIFS, E-mail, FTP, Image, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Image formats supported	BMP, JPG
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	2
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	64 MB
Maximum internal memory	576 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	TFT
Market positioning	Business
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Scan
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP professional x64 Edition, Vista Mac OS X 10.3.9 + Linux
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, Web Services (Print), CIFS Client, SNTP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, Web Services (Print), CIFS Client, SNTP
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	1
Bundled software	Brother MFL-pro suite in Windows: BrotherControlCentre 3 Scansoft Paperport 11SE + OCR, Macintosh:BrotherControlCentre 2 Newsoft Presto! Page manager 7
Power consumption (standby)	85 W
Power consumption (PowerSave)	16 W
Power consumption (average operating)	680 W
Package weight	21800 g
Maximum duty cycle	30000 pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
