Brother DCP 8085DN Service Manual

3-7
Confidential
Jam MP Tray The paper is jammed in
the MP tray of the
machine.
Remove the jammed paper from the
MP tray. 3-26
Jam Tray 1
Jam Tray 2
The paper is jammed in
the paper tray of the
machine.
Remove the jammed paper from the
tray 1 or 2. 3-26
No Paper The machine is out of
paper or paper is not
properly loaded in the
paper tray.
Do one of the following:
Refill the paper in the paper tray or
MP tray.
Remove the paper and load it again.
3-28
No Response/
Busy
The number you dialed
does not answer or is busy.
Verify the number and try again. 3-69
3-70
No Toner The toner cartridge or the
drum unit and toner
cartridge assembly is not
installed properly.
Re-install the toner cartridge or the
drum unit and toner cartridge
assembly.
3-14
No Tray The paper tray is not
completely closed.
Close the paper tray properly.
3-24
Not Registered You tried to access a One
Touch or Speed Dial
number that is not
programmed.
Set up the One Touch or Speed Dial
number.
3-70
Out of Memory The machine’s memory is
full.
Fax sending or copy operation in
progress
Do one of the following:
Press Start to send or copy the
scanned pages.
Press Stop/Exit and wait until the
other operations in progress finish,
and then try again.
Clear the data from the memory.
Print operation in process
Do one of the following:
Reduce print resolution.
Clear the faxes from the memory.
3-26
Print Unable XX The machine has a
mechanical problem.
Perform processing with the error
code.
3-12
3-13
3-18
3-19
3-20
3-21
3-36
3-37
3-38
Protected Device The protect switch of the
USB Flash memory drive
is on.
Turn off the protect switch of the USB
Flash memory drive. 3-35
Rename the File There is already a file on
the USB Flash memory
drive with the same name
as the file you are trying to
save.
Change the file name of the file on
the USB Flash memory drive or the
file you are trying to save.
-
Error Message Type of Error Action
Refer
to

Brother DCP 8085DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	CIFS, E-mail, FTP, Image, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Image formats supported	BMP, JPG
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	2
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	64 MB
Maximum internal memory	576 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	TFT
Market positioning	Business
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Scan
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP professional x64 Edition, Vista Mac OS X 10.3.9 + Linux
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, Web Services (Print), CIFS Client, SNTP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, Web Services (Print), CIFS Client, SNTP
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	1
Bundled software	Brother MFL-pro suite in Windows: BrotherControlCentre 3 Scansoft Paperport 11SE + OCR, Macintosh:BrotherControlCentre 2 Newsoft Presto! Page manager 7
Power consumption (standby)	85 W
Power consumption (PowerSave)	16 W
Power consumption (average operating)	680 W
Package weight	21800 g
Maximum duty cycle	30000 pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
