3-13
Confidential
8 TONER SENSOR PCB UNIT ASSY / NEW TONER SENSOR HARNESS ASSY
Toner sensor PCB unit ASSY
New toner sensor
harness ASSY
Main PCB ASSY
<Left side>
<Front side>
