Analog input for 0dBFS can
be pre-set globally to +28,
+24, +22, +20, +18 or +15
dBu
Pre-fader headroom on
analog inputs is adjustable
globally from +24 to +36dB
in 2dB steps
Analog output for 0dBFS
matches input setting into
>1kOhms (+24dBu max into
600 Ohms)
The system can be pre-
set with up to five external
synchronisation sources,
plus internal, such that if
the 1st source fails, it will
automatically switch to the
2nd, and so on.
SySTEM SPECIfICATION
Formats supported AES/EBU (AES3) 24-bit
Also suitable for use with SPDIF (IEC958 Type 2) signals
Interface 110 Ohm transformer balanced, 5V Pk-Pk
75 Ohm unbalanced (BNC), 1V Pk-Pk
Sample rate conversion 24 bit switchable on all digital inputs
SRC THD+N -117dB @ 1kHz, 0.00014%
Formats supported AES/EBU (AES3) 24-bit
Interface 110 Ohm transformer balanced 4V Pk-Pk (nominal) into 110 Ohm load
75 Ohm unbalanced 1V Pk-Pk (nominal) into 75 Ohm load (BNC)
Analog - digital conversion 24 bit
Input Electronically balanced
Input impedance >1k Ohms for mic gains
10k Ohms for line gains
Sensitivity +18 / -78dB on mic/line input card
+18/-24dB on line only input card.
Equivalent input noise -126dB (150 Ohm source)
Distortion -1dBFS @ 1kHz - Better than 0.003%
-20dBFS @ 1kHz - Better than 0.006%
-60dBFS @ 1kHz - Better than 0.3%
Frequency response 20Hz to 20kHz +/- 0.5dB on mic/line input card
20Hz to 20kHz +/- 0.25dB on line only Iiput card
Input CMR
(Common Mode Rejection)
>70 dB (Typical 80dB) on line inputs
>75 dB (Typical 85dB) on mic inputs
Digital - analog conversion 24-Bit
Output balance Electronically Balanced, 20Hz to 20kHz, Better than -35dB, typically -45dB
Output impedance <40 Ohms
Distortion -1dBFS @ 1kHz - Better than 0.006%
-20dBFS @ 1kHz - Better than 0.003%
-60dBFS @ 1kHz - Better than 0.3%
Frequency response 20Hz to 20kHz +/- 0.25dB
Digital to digital (AES/EBU)
distortion
-1dBFS, 20Hz to 10kHz - Better than 0.002%
Digital to digital (with SRC)
distortion
-1dBFS, 20Hz to 10kHz - Better than 0.005%
Frequency response (Analog
input to output)
20Hz to 20kHz +/- 0.5dB
48kHz synchronization NTSC/PAL video
Internal crystal reference
TTL wordclock (48kHz)
AES/EBU digital input (48kHz)
Operating Non-operating
Temperature range 0°C to +30°C (32°F to +86°F) -20°C to +60°C (-4°F to +140°F)
Relative humidity 25% to 80% Non-condensing 0% to 90% Non-condensing
Maximum altitude 2,000 metres (6500ft)* 15,000 metres (49,000ft)
