PRINCIPAL fEATURES
Up to 320 mono equivalent •
channels: 108 stereo channels
plus 104 mono channels.
Up to 52 full 5.1 surround •
channels allocated from
available channel resource.
8 x 5.1 surround, stereo or •
mono audio groups.
All channels and groups have • 4-band
EQ, 2-band Filters, Compressor/
Limiter and Expander/Gate.
Separate 2-band • EQ and 2-band
Filters for Dynamics side-chain.
Up to 192 mono equivalent assignable •
inserts for outboard gear.
All channels and groups can have a •
direct output or a mix-minus feed.
Direct outputs can be pre EQ, •
pre fader, or post fader.
Automatic cross-fading facility, with •
user-definable fade out and in times.
Additional VCA style grouping system.•
Every channel can route to every buss, •
at the same time, without restrictions.
2 main plus 2 sub-main• stereo
or 5.1 surround outputs
Main and sub-main outputs have • 4-
band EQ, 2-band Filters, Compressor/
Limiter and Expander/Gate.
20• auxiliary outputs which can
be 20 mono or 10 stereo.
48 outputs for multi-track or •
general purpose feeds.
Simultaneous LCRS, stereo •
and mono outputs available
from each 5.1 main output.
Direct input available to group, •
mains, aux and mix-minus busses.
Up to 64 faders, with A and B layers •
of control, plus 2 main output faders
with 2 sub-main outputs available
on a second layer of control.
All faders are motorised •
and touch-sensitive.
A centrally assigned fader allows •
control of any fader from the
optimum listening position.
Comprehensive surround •
panning and monitoring.
User-definable • panels for monitor
selection and control.
Flexible TFT screen-based meters •
with total user-configurability.
Delay available on on channel •
inputs, channel, group and main
insert sends and returns, and
channel and group direct outputs.
Optional I/O expansion via a wide •
area interface such as MADI or
Hydra, Calrec’s sophisticated
audio networking system.
On board Flash ROM memory •
system allows 99 full console
or partial memories.
PC• backup allows an unlimited
number of memories.
Sophisticated • GPIO facilities.
Console operates independently of • PC.
Independent DSP operation •
ensures audio continuity even
during PC or control reset.
Console and racks boot from power •
on in less than 20 seconds.
Full control system reset in less than •
15 seconds with no loss of audio.
Last settings fully restored •
on power-up or reset.
Automatic change over to hot •
spares for power supplies,
control cards and DSP card.
All cards and modules are •
designed to be hot plugged.
All cards and modules are designed •
to initialise upon insertion.
