7-13
Routine Maintenance
7
Replacing the Toner Cartridge
• When pulling out the sealing tape, be careful not to touch the toner cartridge
memory (A) or not to hold the drum protective shutter (B) with your hands.
9 Hold the toner cartridge properly with the arrowed side facing
up as shown in the figure.
(A)
(B)
