2-7
Installing the Printer
2
Installation Site
■ Paper Feeder Unit PF-35P
NOTE
The front feet are 7.8 mm high and their top surface is 12 mm square.
The rear feet are 7.8 mm high, the top surface of the left foot is a rectangle of 21.7 mm x
40 mm, and that of the right foot is 31.7 mm x 40 mm and is L-shaped.
(mm)
26.7 294 40.3
26.7
305.8 28.5
62.7282.454.6
61.927661.8
Front Surface
