Engineering
Bill of Material
41 6.00 KIT 2, INDEXER MOUNTEA
A
Y50324
42 6.00 KIT, GREASE LINE, INDEXEREA
A
Y50709
43 1.00 FABRICATION KIT, 26 IN, PC3000EA
A
Y50965
44 4.00 KIT, STAIR CONNECTION, PC3000EA
A
Y50988
45 1.00 FILTER, HI PRESS, 6 MIC, 1-1/4, 6092 PSIEA H10341
46 12.00 CYL, HYD, BORE 2.5, ROD 1.25, STRK 2.5EA H10364
47 6.00 ADPT, MALE 1/2 JIC, MALE 1/2 ORBEA H15-070120-08-08
48 2.00 ADPT, MALE 1 JIC, MALE 1-1/4 ORBEA H15-070120-16-20
49 1.00 REDUCER, JIC 1 FEM, 1/2 MALEEA H15-070123A-16-08
50 18.00 ELL 90°, MALE 1/2 JIC, MALE 1/2 ORBEA H15-070220-08-08
51 1.00 TEE, UNION, 1/2 JIC MALEEA H15-070401-08
52 8.00 TEE, FEM SWV RUN 1/2, MALE 1/2 JIC EA H15-070432-08-08
53 4.00 TEE, FEM, SWV BRANCH, MALE 1/2 JICEA H15-070433-08
54 1.00 TEE, FEM, SWV BRANCH, MALE 1 IN JICEA H15-070433-16
55 1.00 UNION, BULKHEAD, MALE 1/2 JICEA H15-070601-08-08
56 1.00 UNION, BULKHEAD, MALE 3/4 JICEA H15-070601-12-12
57 4.00 UNION, BULKHEAD, MALE 1 JICEA H15-070601-16-16
58 8.00 ELL 90°, BULKHEAD, MALE 1/2 JICEA H15-070701-08-08
59 4.00 BULKHEAD, TEE, 8 JIC BRANCHEA H15-070959-08-08
60 2.00 ADPT, FEM SWVL 1/4 JIC, MALE 1/4 NPTEA H15-2018-04-04
61 1.00 REDUCER, JIC 1-1/4 MALE, 1 FEM JICEA H15-2215-20-16
62 24.00 FTG, GREASE, 1/8 NPT, PTF-SSEA M10533
63 2.00 BEARING, SPHERICAL PLAIN, 2IN SHAFTEA M14032
64 2.00 SNAP RING, INTERNAL, 3-5/32IN DIAEA M14072
65 6.00 LANYARD, SS, 1/16 DIA x 12 LGEA M10888
66 6.00 PIN, CLEVIS, 0.5 IN, ZN FINISHEA M10960
67 4.00 CAPSCR, HEX HD, 3/4-10UNC x 3.00, GR8EA HH-0750NC-0300-GR8
68 18.00 CAPSCR, HEX SOC HD, 5/16-24UNF x 1.50,SSEA SH-0312NF-0150-SS
69 4.00 LOCKWASHER, 3/4 HELICAL SPRINGEA LW-0750-HS
70 4.00 WASHER, F, 3/4, PLAIN, TYPE AEA FW-0750-A
R01 1.00 REMOTE CONTROL UNIT, CATWALK, ATEXEA
A
Y50808
R02 1.00 KIT, LABELS, SAFETY, ENG, 600VEA
A
Y50416
R03 1.00 HOSE ASSY, CATWALK, 6000PSI, PC3000EA
A
Y51038
R04 1.00 KIT, ELEC, LOOSE PARTS, PC3000EA
A
Y50144
R06 0.00 FILTER ELEMENT, H PRESS, 6 MICRON, FHPEA H10340
R07 1.00 PEDESTAL,CS,RADIO MNT,CATWALKEA DT50457
R08 1.00 ID PLATE, CATWALK, PC3000EA 184100010
R09 1.00 ASSY, ELEC, MAIN PANEL BOX, 600V, PC3000EA
A
Y50153
R10 0.00 NAMEPLATE,CANRIG,15x33,SSEA DT50963
R11 2.00 SHIM,POCKET,BOTTOM,14 GAEA 141102474
R12 2.00 SHIM,POCKET,BOTTOM,12 GAEA 141102475
R13 2.00 SHIM, POCKET, BOTTOM,20 GAEA 141102085
Printed:
1/31/2014
