PC3000 with 26" Deck (PC3000-26) User’s Manual
6-20 Document ID 13-003 v 2.0
Inspection Indication Map
Part Name: Ramp Pivot Posts
Procedure:
Perform a Dry Magnetic Particle Inspection on all welds shown in accordance with ASTM E709.
Acceptance criteria are as defined in ASTM E709. All other areas not indicated must be visually examined
for damage and signs of fatigue.
The following information should be supplied on the Inspection Report as minimum:
Purchase Order #:
Date:
Inspection Report #: Canrig Part #:
Inspector Signature/Stamp: Power Catwalk S/N:
Type of Inspection: Canrig Representative:
Ramp
Catwalk
To Next Page
