General Information
Canrig Drilling Technology Ltd. 3-13
Wireless Terminal
When enabled, the wireless terminal (Figure 3-12) is used to control the Catwalk. For more on the wireless
terminal, see “Wireless Terminal,” page 5-1.
Figure 3-12: Wireless Terminal
Main Electrical Box
The main electrical box (Figure 3-13, page 3-14 and Figure 3-14, page 3-15) is located under the
removable Catwalk floors directly adjacent to the electric motor of the HPU.
Warning!
Opening the main electrical box exposes
personnel to 480 – 600 volts AC.
MC 3200 EX
STATUS
ODS
LOCATOR PIN
CARRIER LIFT
ODS
P-RACK
DS
P-RACK
ODS INDEX
ODS KICKER DS KICKER
OUTER
RAISE
INNER
RAISE
Service Tel: +1 866.433.4345
www.canrig.com
INNER
RAISE
FWD.
BACK
DS INDEX
SKATE
MOTOR START RESET
TERMINAL
START
TERMINAL
ON
TERMINAL
OFF
E-STOP
OUTER
RAISE
UP
DOWN
DS
LOCATOR PIN
To Next Page
